1. The Problem: The High Cost of Manual Deckle Planning
Corrugated box manufacturing operates on razor-thin gross margins of 8% to 14%. When an 1,800mm high-speed corrugator runs a combination of client box sheet sizes (e.g. 520mm width + 640mm width + 480mm width = 1,640mm), the remaining 160mm of unutilized edge trim is shaved off directly into the cyclone shredder as scrap.
At this Sanand plant processing 1,400 metric tons of Kraft paper each month, edge-trim scrap averaged 7.8%. When Kraft paper costs ₹38 to ₹45 per kilogram, every 1% of wasted paper represents an annual financial loss of ₹6.4 Lakhs to ₹7.5 Lakhs directly off the owner's bottom line.
| Corrugator Parameter | Legacy Floor Planning | Arihant AI Corrugation ERP |
|---|---|---|
| Deckle Combination | Corrugator master planner paired orders manually using pen and paper. High trim waste (7.8%). | Algorithmic 1D Cutting-Stock optimizer computes optimal multi-order deckle mix with trim < 1.8%. |
| Reel Inventory Tracking | Paper reels recorded only as gross weight. No live tracking of partial rolls returned from corrugator stand. | Individual barcode tracking by Reel ID, GSM, BF, exact width, and live consumption telemetry. |
| Flute Factor Costing | Estimated fluting consumption on a flat 1.4x factor. Heavy box jobs under-recovered starch and paper. | Exact dynamic take-up calculation (B-Flute: 1.32x, C-Flute: 1.43x, E-Flute: 1.27x) with live starch costing. |
| Customer Quotation | Sales managers took 4 to 8 hours to calculate box paper cost, scoring allowance, and printing dies. | Instant 1-click quote engine: enter L x W x H and FEFO style to generate precise margin-protected pricing. |
Corrugator Deckle Scrap Loss Calculator
Calculate how much money your corrugation plant bleeds annually through edge trim waste, and see your projected savings with Arihant AI.
2. The Solution: Algorithmic 1D Cutting-Stock in Odoo 19
Arihant AI deployed our proprietary corrugation engine on Odoo 19 Enterprise. The architecture operates across three core production stages:
- Automated Order Grouping: Sales orders for standard RSC cartons, die-cut trays, and 5-ply industrial shippers are automatically queued into the production matrix based on matching paper quality (e.g. 140 GSM Top Liner + 120 GSM Fluting + 140 GSM Inside Liner).
- Mathematical Deckle Solving: The heuristic optimizer evaluates thousands of permutations to select the optimal combination of reel widths (1600mm, 1800mm, 2000mm) that yields the lowest trim edge, guaranteeing less than 2% scrap.
- Reel Barcode Weigh-Back: When a corrugator run ends, the partially used Kraft reel is weighed on the return hoist and scanned back into inventory with updated lineal meters and kilogram weight, preventing ghost stock discrepancies.
3. Field Results After 9 Months of Continuous Production
The results verified across the Sanand corrugation unit demonstrate the massive ROI of specialized industrial ERP:
- Average Trim Scrap Reduced to 1.6%: A massive 6.2% absolute drop in waste across 1,400 monthly tons.
- ₹22.8 Lakhs in Raw Kraft Paper Saved: Directly increasing the plant's net profit margin by 3.8%.
- Quotation Velocity: Sales managers responded to client RFQs in under 60 seconds with exact margin safeguards, resulting in a 24% higher conversion rate for high-volume automotive packaging contracts.
"Corrugation is a game of millimeters and paper weight. In our first month with Arihant AI, our edge trim scrap plummeted from over 7% to under 2%. That paper savings paid for the entire ERP implementation in less than four months."
- Managing Director, Corrugated Packaging Plant, Sanand GIDC
4. Book an On-Site Plant Scoping Audit
Our Senior ERP Engineering team is based in Ahmedabad at C-508 Dev Aurum, Prahlad Nagar. We conduct comprehensive on-site plant audits across Gujarat industrial corridors (Sanand, Changodar, Moraiya, Kadi, Chhatral, Vapi, Surat).
Request a Plant Deckle & Costing Audit
Send us your current reel deckles and typical box order sizes for a complimentary mathematical optimization benchmark.
