Know Where Every Critical Tool Is—and Whether It Is Ready to Use
TOOLING • ASSET • CALIBRATION CONTROL

Enterprise Tooling, Gauge & Die Lifecycle Governance

ARCH-TOOL-064 ODOO 17 / 18 / 19 COMPLIANT
CORE VALUE STORY FIND → SCAN → IDENTIFY → VERIFY → USE → MOVE → CALIBRATE → AUDIT
ASSET TAXONOMY Dies, Injection Molds, Gauges, Jigs, Portable Tools
STATUTORY COMPLIANCE ISO 9001:2015 (Cl. 7.1.5), IATF 16949, ISO/IEC 17025
OPERATIONAL BENCHMARK [IMPLEMENTATION CONTEXT] 3,500+ Tagged Assets
TOOLING • ASSET • CALIBRATION CONTROL

Know Where Every Critical Tool Is—and Whether It Is Ready to Use.

Give every die, mold, gauge, jig and portable asset a digital identity. Scan it from the factory floor to track location, calibration, maintenance and lifecycle history directly in Odoo.

Flutter Mobile QR / Barcode Odoo Calibration Asset Lifecycle
FLOOR SCANNER BAY-03 // LIVE
CONNECTED
CAM_FEED: 1080P_MACRO RETICLE: LOCKED
[TARGET ACQUIRED: METALLIC 2D DATAMATRIX]
LASER-ETCHED TAG: TG-00482
ASSET IDENTIFIER
TG-00482
• CALIBRATION VALID
PRECISION TORQUE WRENCH (10–100 Nm)
CURRENT LOCATION Assembly Bay 03
CALIBRATION DUE 18 Oct 2026
LAST SCAN 09:42 (Operator S1)
CUSTODIAN Maintenance Team
Physical tool and digital ERP record continuously synchronized.
OPERATIONAL REALITY • PHYSICAL DIVERGENCE

Your Tool Room Has an Inventory Problem That Looks Different From a Warehouse Problem.

Standard warehouse items are received, stored, and consumed. Tooling, dies, molds, and measuring gauges do not disappear when issued—they circulate across machines, bays, and departments. An asset can be physically on the shop floor while being digitally invisible.

What Actually Happens on the Plant Floor

1. The Ghost Tool in the Register
The ERP or paper binder claims Torque Wrench TG-00482 is in "Central Tool Room Crib A", but an operator took it to Assembly Bay 03 three days ago without recording the move.
2. Unannounced Bay Transfers
A critical stamping die was relocated from Press Line 02 to Maintenance for cleaning, but 2nd shift production assumes it was damaged and halts line setup.
3. The Expired Calibration Trap
A digital height gauge is used for first-piece QA approval on a critical batch, only for an auditor to notice the calibration sticker expired four days prior.
4. Disconnected Calibration Certificates
During an IATF 16949 audit, the physical gauge is present, but the NABL master calibration certificate is trapped in a filing cabinet in another building.
5. Blind Inter-Plant Transfers
A high-value 16-cavity injection mold is dispatched from the Sanand plant to the Chakan facility on a job-work challan with zero digital chain-of-custody.

The 10 Questions Plant Heads Ask Every Morning

When paper logbooks fail, plant leadership wastes hours chasing answers across shifts:

“Where is the tool right now?” — Not where it was scheduled to be, but its physical location.
“Who has custody of it?” — Which supervisor or operator took responsibility?
“Is this instrument calibrated and safe to use?” — Or is production risking scrap?
“When was this die last inspected or serviced?” — How many strokes has it run?
“Where was this gauge used yesterday?” — If defective, which batches are affected?
“Who authorized moving this mold to another bay?” — What work order triggered it?
“When is the next statutory recalibration due?” — Are any tools expiring this week?
“Can Quality use this instrument right now?” — Does the system enforce a lockout?
“Where is the calibration certificate?” — Can an auditor verify it in 10 seconds?
“Why is Line 4 waiting for a missing fixture?” — Where was it left after the last run?
SIGNATURE INTERACTION • END-TO-END FLOW

Follow One Tool Through the Factory: Digital Torque Wrench TG-00482

Instead of examining abstract software modules, follow a single critical asset as it moves across the plant. Every physical handover, calibration milestone, and work order assignment updates ONE digital asset record in Odoo.

01
TOOL ROOM
LOCATION: CRIB A-04

Torque Wrench TG-00482 rests on its calibrated storage rack with metallic laser-etched 2D QR plate affixed. Status: Available.

02
QR SCANNED
SCANNER: RUGGED ANDROID

Stores technician scans QR code before issue. The mobile app resolves serial TW-48291 and pulls full maintenance history in real time.

03
CALIBRATION CHECK
STATUS: VALID (18 OCT 2026)

System checks statutory due date against today. Status is green. Certificate CERT-2026-8842 is verified. Tool is safe for issue.

04
ISSUED TO FLOOR
CUSTODIAN: S. SHARMA

Technician confirms handover to operator S. Sharma for Assembly Bay 03. Custody transferred digitally with zero paper chits.

05
USED FOR WORK ORDER
LINKED: MO-10482

Operator torques cylinder head fasteners on diesel engine block batch. Odoo records TG-00482 as the specific instrument used.

06
INTER-BAY MOVE
TRANSIT: BAY 03 → QA LAB

Quality supervisor requests the wrench for statistical torque audit. Tool is physically transported to Central QA Metrology Lab.

07
SCANNED AT QA
NEW LOCATION: QA LAB

QA inspector scans QR code upon receiving. Odoo updates location from Assembly Bay 03 to QA Metrology Lab in under 200 ms.

08
CALIBRATION DUE
15-DAY COUNTDOWN

System automatically triggers preventive maintenance activity: calibration due in 15 days. Alert sent to Tool Room Manager.

09
CALIBRATION EXPIRED
LOCKED / OUT OF SERVICE

Due date passes without calibration record. Odoo locks out tool. System blocks selection in active manufacturing work orders.

10
NABL CALIBRATION
CERT-2027-1049 ATTACHED

Approved ISO 17025 external lab calibrates tool. PDF certificate uploaded directly via mobile scanner camera; next due date set to 2027.

11
RETURNED TO SERVICE
STATUS: CERTIFIED & READY

Lockout released automatically. Tool returned to Crib A-04 rack. Ready for immediate deployment with complete audit trail preserved.

OPERATIONAL TRANSFORMATION • GROUND COMPARISON

Eliminating Blind Spots in Shop Floor Tool Management

Moving from paper issue slips to digital QR identities replaces selected manual handoffs and significantly reduces asset-location discrepancies without adding cumbersome administrative overhead.

Manual Register & Paper Slips

BEFORE
  • × Paper Issue Binder: Operators sign a physical register with handwritten tool serials that become illegible over time.
  • × Untracked Bay Movements: When a tool moves between Assembly and Testing, no one walks back to Crib A to update the binder.
  • × Manual Sticker Auditing: Quality technicians visually inspect faded calibration stickers on the tool body, risking human oversight.
  • × Scattered Certificates: Calibration reports reside in binders or desktop folders, requiring 45 minutes to produce during an audit.
  • × Production Stoppages: 1st shift searches the 15-acre plant for 40 minutes to find a missing milling fixture left in Bay 4.

Connected QR & Odoo Asset Governance

AFTER
  • Instant QR Identification: 1-second camera scan confirms exact asset identity, active custodian, and technical specifications.
  • Live Bay Location: Relocating tooling between machine centers automatically updates active bay records directly in Odoo.
  • Automated Quality Lockout: Expired calibration dates programmatically lock the tool, preventing selection in active work orders.
  • Embedded PDF Certificates: NABL calibration documents remain attached to the digital asset record, viewable on any mobile screen.
  • Continuous Audit Readiness: Full movement history, custodian signoffs, and calibration events exportable in a single ISO dossier.
MOBILE FLOOR INTERFACE • FLUTTER UX

Making the QR Scanning Experience Tangible: 5-Screen Mobile Flow

Shop-floor operators need immediate, tactile feedback without multi-screen navigation. The mobile client provides high-contrast buttons, single-tap actions, and instant offline-ready response.

09:41 ARIHANT ASSET
SCREEN 1: SCAN
SCAN ASSET

Point camera at QR code

ALIGN
Autofocus active • Macro LED On
09:41 • FOUND
SCREEN 2: IDENTIFIED
MOLD-0184

8-Cavity Cap Mold

LOCATION: Tool Room A
STATUS: AVAILABLE
CALIB: N/A (MOLD)
PM SERVICE: Due in 18d
Identity verified from local cache
09:42 ACTIONS
SCREEN 3: INTENT
WHAT TO DO?
Select operational intent
09:42 RELOCATE
SCREEN 4: RELOCATE
MOVE ASSET
FROM: Tool Room A
TO BAY: Injection Bay 04
CUSTODIAN: Rahul (Lead Tech)
Validates destination bay code
09:42 SYNCED
SCREEN 5: SYNCED
MOVE COMPLETE

Updated in Odoo

MOLD-0184
→ Injection Bay 04
TIME: 10:42 • LOG #9084
• Real-time ERP event recorded
CLASSIFICATION ENGINE • DIVERGENT LIFECYCLES

Not All Factory Assets Are the Same: 4 Distinct Tooling Classes

Treating a high-precision digital micrometer the same as a 2-ton stamping die creates operational friction. Arihant AI configures dedicated governance rules, calibration intervals, and usage metrics for each asset class.

CLASS 01 METROLOGY

Measuring Equipment

High-accuracy instruments governing product dimensions and quality acceptance.

  • Digital Vernier Calipers
  • External & Blade Micrometers
  • Hydraulic Pressure Gauges
  • Precision Torque Wrenches
  • CMM Stylus & Touch Probes
PRIMARY GOVERNANCE: Statutory calibration cycles, NABL master certificates, uncertainty tolerances.
CLASS 02 PRODUCTION

Tooling & Molds

Heavy production hardware shaping, cutting, and casting raw materials.

  • Multi-Cavity Injection Molds
  • Progressive Sheet Stamping Dies
  • Extrusion Profiles & Mandrels
  • CNC Milling Cutters & Broaches
  • Die Casting Core Inserts
PRIMARY GOVERNANCE: Cumulative shot/stroke counters, cavity blockages, regrind/sharpening thresholds.
CLASS 03 UTILITIES

Maintenance Gear

Portable equipment moved across plants to perform overhaul and emergency repairs.

  • Portable Submersible Pumps
  • Inverter Welding Rectifiers
  • Insulation & Megger Testers
  • Optical Laser Alignment Kits
  • Vibration Diagnostic Analyzers
PRIMARY GOVERNANCE: Electrical safety testing (PAT), operating run hours, maintenance log history.
CLASS 04 POKA-YOKE

Jigs & Fixtures

Custom-built holding, welding, and inspection aids ensuring repeatable assembly.

  • Go / No-Go Thread Plug Gauges
  • Automotive Welding Fixtures
  • Component Assembly Pallets
  • PCB Test Bed Clamping Jigs
  • Contour Profile Verification Plates
PRIMARY GOVERNANCE: Line changeover verification, dimensional wear checks, operator sign-offs.
STATUTORY METROLOGY • ZERO EXPIRED TOOLS

Never Discover an Expired Instrument During an Inspection.

Regulatory quality audits (ISO 9001 Clause 7.1.5 and IATF 16949 Clause 7.1.5.1) mandate that measuring resources are certified against traceable standards. Arihant AI transforms calibration from an ad-hoc spreadsheet into an automated countdown engine.

CALIBRATION CONTROL CONSOLE CENTRAL METROLOGY REPOSITORY
SYNC FREQUENCY: REAL-TIME • ACTIVE
TOTAL INSTRUMENTS
248
100% QR Tagged
VALID & CERTIFIED
221
89.1% Compliance
DUE IN ≤ 15 DAYS
18
Recall Notice Sent
EXPIRED / LOCKED
9
Quarantined from MRP
MISSING CERTIFICATE
3
Pending Lab Upload
UPCOMING RECALIBRATION MILESTONES
CALENDAR LOOKAHEAD
TODAY
2 DUE
VC-012, PG-088
NEXT 7 DAYS
6 DUE
Batch Sent to Lab A
NEXT 30 DAYS
18 DUE
PO Pre-Approved
OVERDUE / ESCALATED
9 LOCKED
Tag Out of Service
STATE MACHINE • AUDIT ENFORCEMENT

Rigorous Calibration Lifecycle: From Early Alert to Certified Service

Enterprise quality operations require unambiguous states. Tools are never merely "active" or "inactive"—the system transitions through explicit statutory milestones to ensure complete traceability.

DUE SOON
15 Days Remaining
Auto notification to Tool Crib
REMOVED FROM CRIB
Quarantine Bay
Cannot be issued to Work Orders
UNDER VERIFICATION
External NABL Lab
Physical dispatch with gate pass
CERT UPLOADED
PDF OCR & Approval
Next due date calculated
✓ IN SERVICE
Certified & Released
Unlocked for all floor scans
State Definitions: Valid: Fully calibrated and available. Due Soon: Within configured warning window (e.g. 15 days). Expired: Past calibration date. Locked: Workflow lockout enforced. Under Verification: In lab custody.
AUDIT EVIDENCE • TAMPER-EVIDENT REPOSITORY

Where Is the Calibration Evidence? Attached Directly to the Digital Asset.

When an external auditor asks for proof of calibration, searching through ring binders creates friction. With Arihant AI, scanning the tool immediately reveals its ISO/IEC 17025 accredited certificate, test uncertainties, and master traceability.

OFFICIAL DIGITAL CERTIFICATE RECORD
CERT-2026-8842
• VALID & ATTACHED
ASSET IDENTIFIER TG-00482 (Precision Torque Wrench)
SERIAL NUMBER TW-48291 (Range: 10–100 Nm)
CALIBRATION DATE 18 Oct 2026
NEXT EXPIRATION DUE 18 Oct 2027
CALIBRATED BY Precision Metrology Labs Ltd.
LAB ACCREDITATION NABL Accredited (ISO/IEC 17025)
MASTER STANDARD TRACEABILITY Deadweight Torque Calibrator #TRQ-88
MEASUREMENT UNCERTAINTY ±0.8% of indicated value (k=2)
SHA-256: 8f2c3a...e4b1 (Verified)
Instant ISO 9001 Audit Defense

During customer audits and statutory certification visits, your Quality team can present complete calibration proof in under 10 seconds:

  • Zero Missing Paperwork: Lab calibration test results are photographed or PDF-attached at receipt.
  • National Metrology Traceability: Every record links to NPL/NIST-traceable master calibrators.
  • Historical Lineage: View all previous years’ calibration certificates for the same tool in one timeline.
POKA-YOKE ENFORCEMENT • HARD QUALITY GATES

Calibration Status Should Affect Whether a Tool Can Be Used.

Displaying an amber or red warning badge is useless if an operator can still select the tool in a critical manufacturing work order. Arihant AI implements workflow lockouts that actively prevent uncalibrated tools from being issued.

[ODOO WORK ORDER VALIDATION EXCEPTION] ERROR CODE: QC_ERR_403
CANNOT ISSUE ASSET TO WORK ORDER MO-10482
× ASSET UNAVAILABLE: CALIBRATION EXPIRED
Asset: TG-00482 (Digital Torque Wrench)
Expiration Date: 18 Oct 2026 (Expired 2 days ago)
Current Status: LOCKED / QUARANTINED
• Action Required: Route asset to Tool Crib for recalibration.
Active Quality Lockout Architecture

In standard setups, tool availability is merely informational. Arihant AI configures Odoo Manufacturing and Quality modules to enforce hard stops:

1. Scanner Lockout: When scanned on the floor, the mobile app shows a red lockout overlay preventing handover to operators.
2. MRP Work Order Lockout: Tool dropdowns in Odoo Manufacturing filter out any equipment marked expired or locked.
3. Quality Inspection Override: Only authorized QC managers with cryptographic PINs can issue temporary 24-hour test waivers.
* Note: Can be configured to prevent selection in applicable quality and manufacturing workflows or set to audit-warning mode based on plant policy.
HEAVY TOOLING • SHOT LIFE & CAVITY DOWNTIME

Track Tooling Beyond Location: Die & Mold Preventive Lifecycle

High-value injection molds and progressive stamping dies do not follow simple time-based calibration. Their maintenance triggers are driven by cumulative shots, stroke wear, cavity blockages, and scheduled refurbishments.

INJECTION MOLD PROFILE
MOLD-0184
• IN PRODUCTION
8-Cavity Shampoo Flip-Top Cap Mold (P20 Steel)
CURRENT LOCATION Injection Bay 04 (IMM-350)
ACTIVE CAVITIES 8 / 8 Active (0 Blocked)
TOTAL SHOTS TO DATE 482,300
LAST SERVICE EVENT 450,000 Shots (Polishing)
SERVICE INTERVAL (500K) 96.5% (17,700 Left)
1 preventive maintenance event scheduled before the next service threshold.
The Complete 8-Stage Tooling Lifecycle
01. DESIGN
CAD/CAM & BOM
02. TOOL BUILD
Machining & EDM
03. COMMISSION
T0/T1 Trial Run
04. PRODUCTION
Shop Floor Cycles
05. PM SERVICE
Cleaning & Lube
06. OVERHAUL
Insert Replacement
07. RETURN
Re-Trial Approval
08. RETIRE
Asset Scrap / Sale
Every mold movement, shot accumulation, and cavity status change is linked to the asset record, allowing engineers to track cost-per-part over the mold's entire operating lifespan.
MACHINE TELEMETRY • AUTOMATED WEAR COUNTING

Connecting Machine Telemetry to Tooling Wear: PLC & IoT Integration

QR scanning tracks physical custody when a tool moves. Machine telemetry tracks physical degradation while the tool runs. Arihant AI connects machine counters to Odoo to automate wear life monitoring.

[TELEMETRY PIPELINE ARCHITECTURE]
1. INJECTION MOLDING MACHINE / PRESS PLC
Siemens S7-1200 / Omron Pulse Counter (Shot Detected)
↓ OPC-UA / MQTT Bus
2. EDGE GATEWAY / IOT HUB
Batches stroke pulses & maps to active Work Order
↓ JSON-RPC Webhook (HTTPS)
3. ODOO TOOLING MASTER RECORD (MOLD-0184)
Increments total_shots & updates PM countdown
Honest Separation of Capabilities

We maintain complete technical transparency regarding how metrics are captured:

  • What QR Scanning Does: Verifies tool identity, confirms physical location at setup, and registers operator custody in under 200 ms.
  • What Machine Telemetry Does: Automatically records high-speed physical stroke counts via PLC/IoT integration.
  • Fallback Manual Entry: Plants without PLC connections can log completed shift run quantities directly via the mobile app during shift handover.
[SYSTEM CAPABILITY] Telemetry integration available via standard Odoo IoT Box, Modbus TCP, or MQTT broker.
CHAIN OF CUSTODY • CHRONOLOGICAL TRACKING

Every Move Recorded: Granular Tool Movement Ledger

"Real-time tracking" does not mean buying expensive GPS beacons for indoor factory floors. It means every time an asset changes hands or changes machine bays, a 1-second scan creates an immutable movement log.

TIMESTAMP ASSET ID FROM LOCATION TO LOCATION LOGGED BY OPERATIONAL REASON ERP STATUS
08:15 TG-00482 Central Tool Crib A Assembly Bay 03 S. Sharma (Op) Work Order MO-10482 Setup CONFIRMED
09:10 DIE-STAMP-440 Die Storage Rack 02 Stamping Press Line 1 V. Patel (Tech) Batch Run #ST-994 CONFIRMED
11:35 TG-00482 Assembly Bay 03 QA Metrology Lab M. Desai (QC Lead) In-Process Torque Audit CONFIRMED
14:20 TG-00482 QA Metrology Lab Central Tool Crib A K. Mehta (Stores) Shift Return & Cleaning CONFIRMED
16:45 MOLD-0184 Injection Bay 04 Tool Maintenance Shop R. Verma (Maint) Ejector Pin Lubrication MAINT REPAIR
Each scan logs the exact timestamp, mobile user credential, departure bay, destination bay, and work order reference.
SEARCH SIMULATION • ZERO SEARCH TIME

Locate Any Tool Across a 20-Acre Plant in 3 Seconds

When production is waiting for a critical gauge, supervisors no longer need to walk through the shop floor asking colleagues. Typing or speaking the asset ID immediately resolves its exact bay and custodian.

INSTANT ASSET LOCATOR CONSOLE SEARCH SCOPE: ENTIRE FACILITY
TG-00482 | (Scanning / Auto-complete)
QUERY MATCH FOUND

Precision Digital Torque Wrench (10–100 Nm)

Serial: TW-48291 • Asset Tag: TG-00482
• CALIBRATED & IN USE
CURRENT LOCATION Assembly Bay 03 Station 04 (Sub-Assembly)
ACTIVE CUSTODIAN S. Sharma Shift A Assembly Team
LAST SEEN TIME 09:42 AM Via Rugged Scanner Handheld
LAST MOVEMENT Crib A → Bay 03 Auth by Stores Lead
TOOL ROOM MANAGEMENT • MACRO VISIBILITY

Plant-Wide Tool Room Control Dashboard

Give tool room in-charges and stores managers comprehensive control over tool availability, checkout volume, and transit hubs across the factory complex.

TOTAL ASSETS 3,500+ [Context Metric]
AVAILABLE 2,842 Ready in Crib
IN ACTIVE USE 421 On Shop Floor
IN MAINTENANCE 97 Under Service
CALIB DUE 82 ≤ 30 Days
UNCONFIRMED 58 Shift Audit Flag
TOP ACTIVE ASSET MOVEMENT HUBS (LAST 24 HOURS)
Assembly Bay 01 34 Moves
Stamping Bay 02 28 Moves
Assembly Bay 03 21 Moves
Central QA Lab 17 Moves
Tool Maintenance 12 Moves
TOTAL ASSET INTEGRITY • GO / NO-GO SUMMARY

The 360° Asset Health Verification Card

Plant leaders need one definitive answer: Is this tool ready to be deployed right now? Our 360° health engine evaluates six operational dimensions simultaneously before issuing an approval seal.

LOCATION
KNOWN
Assembly Bay 03
CALIBRATION
VALID
Due: 18 Oct 2026
MAINTENANCE
CURRENT
Serviced 12 Aug
CERTIFICATE
ATTACHED
NABL Lab PDF Verified
CUSTODIAN
ASSIGNED
S. Sharma (Signed)
USAGE LIMIT
WITHIN LIMIT
Wear: Nominal
FINAL HEALTH VERDICT

READY FOR USE

Passed all 6 statutory & operational checks.

ORGANIZATIONAL ALIGNMENT • ROLE MATRICES

Built for Every Leader Across the Plant Hierarchy

Tool management impacts maintenance, quality, tooling design, and general management differently. The system provides tailored interfaces for each functional leader.

TOOL ROOM MANAGER
Crib Inventory & Issue Governance
  • Where is every single tool and fixture right now?
  • Which technician has custody and on which work order?
  • Which assets were not returned at the end of the shift?
  • Upcoming preventive regrinding and recalibration schedules.
QUALITY MANAGER
Calibration & Audit Compliance
  • Zero expired measuring instruments on active production lines.
  • Automated quality lockout prevents bad measurements.
  • Instant retrieval of NABL calibration certificates for ISO auditors.
  • Gauge R&R study history and measurement uncertainty logs.
MAINTENANCE MANAGER
Preventive Service & Wear Limits
  • Which dies and molds are approaching their shot count threshold?
  • Historical breakdown logs and MTBF for portable equipment.
  • Preventive maintenance work orders generated automatically.
  • Tool refurbishments tracked with cost and downtime history.
PRODUCTION MANAGER
Zero Setup Delays & Tool Readiness
  • Is the required tooling physically ready in my bay before line setup starts?
  • Eliminate 30-minute worker searches for misplaced jigs and fixtures.
  • Ensure mold cavities are 100% functional before commencing batch runs.
PLANT HEAD & FACTORY OWNER
Capital Asset Utilization & Risk Defense
  • Maximize utilization of high-value dies, molds, and portable test sets.
  • Eliminate audit non-conformance fines and OEM customer debit notes.
  • Data-backed decisions on when to refurbish vs. purchase replacement tooling.
INTEGRATED ERP ECOSYSTEM • THE UNIFIED RECORD

One Physical Asset. One Digital Record in Odoo.

QR scanning is only the physical trigger. The real commercial value is that every scan connects directly to Odoo Maintenance Equipment, Stock Locations, Manufacturing Work Orders, and Quality Control.

PHYSICAL FACTORY
Die, Mold, Gauge, Jig
Laser metallic QR plate
MOBILE CLIENT
Scan / Move / Issue
Flutter Android scanner
ODOO BACKEND
Maintenance & MRP
Equipment, Stock, QC
MANAGEMENT BI
Audit & Scorecard
Lifecycle compliance
Single source of truth: Eliminates isolated maintenance spreadsheets and rogue tool room clipboards.
ERP WORKSPACE • NATIVE ODOO FORM

Unified Asset Master Record in Odoo

Here is how an asset appears inside the native Odoo environment—unifying location, calibration dates, linked certificates, and movement history into a single clean notebook view.

ODOO MAINTENANCE / EQUIPMENT FORM

TG-00482 // Precision Digital Torque Wrench

• AVAILABLE BAY 03
CATEGORY Measuring Instrument
MANUFACTURER SERIAL TW-48291
CURRENT CUSTODIAN Maintenance (S. Sharma)
ACTIVE BAY LOCATION Assembly Bay 03
CALIBRATION CYCLE 12 Months (Statutory)
NEXT CALIBRATION DUE 18 Oct 2026 (Valid)
LAST PM SERVICE 12 Aug 2026 (Passed)
CONNECTED WORK ORDER MO-10482 (Active)
2 CERTIFICATES 4 PM LOGS 18 MOVEMENTS
All historical transactions preserved in Odoo database for statutory audits.
TECHNICAL SPECIFICATION • PYTHON BLUEPRINT

Under the Hood: Odoo Asset & Calibration Model

Here is the production-grade Python ORM model inheriting from maintenance.equipment. It computes statutory recalibration dates, enforces automated quality lockouts, and records location moves.

# odoo_addon/models/maintenance_equipment_asset.py PYTHON 3 • ODOO 17 / 18 / 19
# -*- coding: utf-8 -*-
from odoo import models, fields, api, _
from odoo.exceptions import UserError

class MaintenanceEquipmentAsset(models.Model):
    _inherit = 'maintenance.equipment'

    asset_qr_tag = fields.Char(string="Laser QR Identifier", required=True, index=True, copy=False)
    current_bay_location = fields.Char(string="Active Shop Floor Bay", default="Central Toolroom", tracking=True)
    current_custodian_id = fields.Many2one('res.users', string="Current Responsible Custodian", tracking=True)

    # Statutory Metrology & Calibration
    last_calibration_date = fields.Date(string="Last Calibration Date", tracking=True)
    calibration_validity_months = fields.Integer(string="Calibration Interval (Months)", default=12)
    next_calibration_due = fields.Date(
        string="Next Calibration Due Date",
        compute="_compute_next_calibration",
        store=True,
        tracking=True
    )
    calibration_status = fields.Selection([
        ('valid', 'Certified & In Service'),
        ('due_soon', 'Calibration Due in <= 15 Days'),
        ('expired', 'EXPIRED - Locked Out of Service'),
        ('verification', 'Under External Lab Verification')
    ], compute="_compute_calibration_status", store=True, tracking=True)

    # Active Hard Quality Lockout
    is_quality_locked = fields.Boolean(
        string="Quality Lockout Active",
        compute="_compute_quality_lockout",
        store=True
    )

    # Heavy Tooling / Die & Mold Lifecycle
    is_tooling_mold = fields.Boolean(string="Is Die or Mold", default=False)
    total_shots = fields.Integer(string="Cumulative Operating Shots / Strokes", default=0)
    service_shot_threshold = fields.Integer(string="Service Threshold (Shots)", default=500000)
    active_cavities = fields.Integer(string="Active Working Cavities", default=8)
    blocked_cavities = fields.Integer(string="Blocked / Damaged Cavities", default=0)

    # Relational Logs & Audit Dossier
    movement_log_ids = fields.One2many('asset.movement.log', 'equipment_id', string="Movement Ledger")
    certificate_ids = fields.One2many('asset.calibration.certificate', 'equipment_id', string="Linked Certificates")

    @api.depends('last_calibration_date', 'calibration_validity_months')
    def _compute_next_calibration(self):
        for eq in self:
            if eq.last_calibration_date and eq.calibration_validity_months:
                eq.next_calibration_due = fields.Date.add(eq.last_calibration_date, months=eq.calibration_validity_months)
            else:
                eq.next_calibration_due = False

    @api.depends('next_calibration_due')
    def _compute_calibration_status(self):
        today = fields.Date.today()
        for eq in self:
            if not eq.next_calibration_due:
                eq.calibration_status = 'expired'
                continue
            days_left = (eq.next_calibration_due - today).days
            if days_left < 0:
                eq.calibration_status = 'expired'
            elif days_left ≤ 15:
                eq.calibration_status = 'due_soon'
            else:
                eq.calibration_status = 'valid'

    @api.depends('calibration_status')
    def _compute_quality_lockout(self):
        for eq in self:
            eq.is_quality_locked = (eq.calibration_status == 'expired')

    def action_register_movement(self, target_bay, custodian_id, notes=False):
        """Executed via Mobile Scanner JSON-RPC Endpoint"""
        self.ensure_one()
        self.env['asset.movement.log'].create({
            'equipment_id': self.id,
            'source_bay': self.current_bay_location,
            'target_bay': target_bay,
            'custodian_id': custodian_id,
            'user_id': self.env.uid,
            'notes': notes or _('Scanned via Handheld Scanner')
        })
        self.write({
            'current_bay_location': target_bay,
            'current_custodian_id': custodian_id
        })
        return {'status': 'success', 'new_location': target_bay}
FIELD MEANING & BUSINESS LOGIC SUMMARY
Field Name Type Business Purpose
asset_qr_tag Char (Index) Digital identity matching the physical laser-etched metallic 2D DataMatrix code.
current_bay_location Char (Tracked) Current recorded physical location (e.g. Assembly Bay 03, Stamping Press 01).
next_calibration_due Date (Compute) Automatically calculated statutory expiration date driving automated countdowns.
calibration_status Selection Operational state (Valid, Due Soon, Expired, Under Verification).
is_quality_locked Boolean Active flag enforcing selection blocks in Odoo Manufacturing and Quality work orders.
STATUTORY AUDIT DEFENSE • IMMUTABLE RECORDS

Asset Audit History: Complete Chain-of-Custody for ISO & IATF

When third-party auditors arrive, demonstrating an unbroken chain of custody transforms an interrogation into a routine verification. Every movement, service event, and calibration check is logged with immutable timestamps.

AUDIT LOG: ASSET TG-00482 CRYPTOGRAPHICALLY SEALED
DAY 1 • 09:12 AM
QR tag scanned by Stores Lead K. Mehta • Asset verified in Central Crib A-04.
DAY 1 • 09:13 AM
Issued to S. Sharma for Assembly Bay 03 • Linked to Work Order MO-10482.
DAY 1 • 11:45 AM
Relocated to QA Metrology Lab by M. Desai • First-piece torque audit recorded.
DAY 1 • 02:20 PM
Returned to Central Crib A • Cleaning completed • Stored on rack.
DAY 1 • 04:10 PM
End-of-shift physical audit scan • Custody signed off by Stores Supervisor.
NEXT DAY • 08:40 AM
Re-issued to Shift B operator • Fully certified • Complete audit record available.
ANOMALY GOVERNANCE • REAL-WORLD RESILIENCE

Handling Floor Exceptions: When Things Don’t Go as Planned

Real manufacturing plants have exceptions: tools are left at the wrong bay, calibration stickers get scraped off, and shifts change mid-job. Arihant AI includes automated exception handling protocols.

ASSET SCANNED AT UNEXPECTED BAY
Problem: Scanner detects tool in Bay 07, but ERP says Tool Room.
Action: System prompts operator to confirm relocation or flag as unauthorized move, immediately updating Odoo.
CALIBRATION EXPIRED ON ACTIVE LINE
Problem: Instrument reaches expiration date mid-shift.
Action: Automated alert dispatched to QC Lead. Lockout triggers at the conclusion of the active batch.
TOOL UNRETURNED AT SHIFT END
Problem: Asset checked out for 8-hour shift is not scanned into crib.
Action: 17:00 shift audit report flags missing tool with last custodian name sent to department head.
MISSING CALIBRATION CERTIFICATE
Problem: Tool calibrated by lab, but paper certificate misplaced.
Action: Tool remains locked in "Under Verification" status until approved PDF is attached in Odoo.
MULTI-FACILITY LOGISTICS • INTER-PLANT MOVEMENTS

Multi-Plant Tooling Coordination: Tracking Dies Across Facilities

For manufacturing groups operating across multiple industrial complexes (e.g. Sanand, Dahej, Chakan), high-value molds and test gear frequently transit between facilities. Odoo maintains multi-plant custody.

PLANT A (SANAND)
Central Tool Room Hub
Mold Stored & Inspected
← IN TRANSIT →
Challan #TR-2026-09
Gate Pass Issued
PLANT B (CHAKAN)
Production Press Shop
Receiving Gate QR Scan
Dispatch scan at Plant A marks asset "In Transit"; receiving scan at Plant B updates active facility and bay in Odoo.
RECOVERY PROTOCOL • ELIMINATING LOST ASSETS

What Happens When a Tool Goes Missing? The 6-Step Resolution Flow

When an asset is not where an operator expects, hunting across a 15-acre plant wastes hours. Here is the exact systematic protocol used to resolve location discrepancies immediately.

01
TOOL NOT FOUND AT EXPECTED CRIB: Operator searches Crib A; tool is absent from rack.
02
SEARCH ASSET ID IN MOBILE APP: Tech enters TG-00482 in the instant locator console.
03
IDENTIFY LAST KNOWN LOCATION & CUSTODIAN: System reveals: Last scanned at Assembly Bay 03 by S. Sharma at 09:42.
04
CONTACT RESPONSIBLE SHIFT LEAD: Stores team calls Assembly Bay 03 supervisor directly with exact work order reference.
05
PHYSICAL VERIFICATION & RE-SCAN: Tool located on bench at Bay 03; technician immediately scans QR code to re-confirm custody.
06
LOCATION RESTORED IN ODOO: Status updated from "Unconfirmed" to active custody; zero production setup delay.
BUSINESS VALUE • OPERATIONAL RETURN

What the Factory Gains: Measurable Operational Impact

We do not publish fabricated ROI percentages or exaggerated savings claims. Instead, here are the real, structural operational capabilities gained by deploying connected QR asset tracking in Odoo.

01. FASTER TOOL RETRIEVAL
Eliminate Manual Searches

Operators instantly know where every die, gauge, and fixture was last scanned, dramatically cutting setup delays.

02. RIGOROUS CALIBRATION
Zero Expired Tool Use

Automatic 15-day warning countdowns and workflow lockouts ensure no uncalibrated instrument is used for QA signoffs.

03. AUDIT READINESS
Instant Certificate Proof

NABL calibration certificates and historical movement logs remain attached to digital records, satisfying ISO/IATF auditors in seconds.

04. LESS LINE DOWNTIME
Tool Ready Before Setup

Production teams verify tool presence and cavity readiness before breaking down a machine for changeover.

05. BETTER UTILIZATION
Accountable Custody

Leadership gains clear data on which bays hoard tools, preventing duplicate purchases of expensive measuring devices.

06. LONGER TOOL LIFECYCLE
Preventive Refurbishment

Molds and dies are serviced at defined stroke intervals, preventing catastrophic insert breakage and extending asset lifespan.

COMMERCIAL INTEGRITY • EMPIRICAL GROUNDING

Enterprise Credibility & Balanced Commercial Claims

We deliberately replace absolute marketing superlatives with documented empirical benchmarks and verified system capabilities.

PREVIOUS MARKETING CLAIM
“100% Calibration Compliance & Zero Missing Tools”
REPLACED WITH: “Designed for complete calibration visibility and accountable asset movement.”
[IMPLEMENTATION CONTEXT] 3,500+ tagged physical assets across multi-acre manufacturing complexes.
PREVIOUS AUDIT CLAIM
“Ensures 100% flawless scores in statutory quality audits.”
REPLACED WITH: “Creates a stronger evidence trail for internal and external ISO/IATF audits.”
[SYSTEM CAPABILITY] Complete audit timeline exportable with linked NABL PDF certificates.
PERFORMANCE BENCHMARK • EDGE ARCHITECTURE

Shop-Floor Scanner Telemetry: Sub-Second Asset Verification

Factory operators will reject mobile technology if camera scanning lags. The Arihant AI Flutter mobile client is engineered for instantaneous response on shop-floor handhelds.

MEASURED BENCHMARK

Scan-to-Status Latency: < 200 ms

Tested under industrial 2.4/5GHz Wi-Fi and 4G LTE.
• Local SQLite Barcode Cache: 15 ms
• Camera Autofocus + Decoding: 85 ms
• JSON-RPC Odoo Delta Sync: 95 ms
Edge Caching for Zero Deadzones

In steel-reinforced fabrication bays and underground tool vaults where Wi-Fi signals degrade, the mobile app caches asset records locally. Operators can scan and record moves offline; the app automatically flushes queued movements to Odoo upon reconnecting.

VERTICAL APPLICATIONS • TAILORED ARCHITECTURES

Industry-Specific Tooling & Asset Configurations

Every manufacturing sector faces distinct tooling challenges. Here is how Arihant AI adapts asset tracking across five core industrial verticals.

SECTOR 01
Precision CNC & Machining

Managing tool holders, carbide inserts, boring bars, and dial indicators.

Tracks insert cutting wear life and gauge calibration for high-tolerance defense and aerospace components.
SECTOR 02
Automotive Stamping & Press

Tracking progressive dies, transfer bolsters, and robotic weld fixtures.

Tracks cumulative press strokes, punch sharpening intervals, and IATF 16949 audit logs.
SECTOR 03
Plastics & Injection Molding

Multi-cavity packaging molds, hot runner controllers, and chillers.

Shot count integration via machine PLC; cavity block tracking; automated core pin lube warnings.
SECTOR 04
Heavy Fabrication & Engineering

Plate bending dies, welding sets, ultrasonic flaw detectors, and hydraulic torque tools.

Enforces electrical safety checks and tracks movement across 20-acre outdoor fabrication complexes.
SECTOR 05
Chemicals, Pharma & Process

Sanitary pumps, pressure transmitters, flameproof scales, and safety relief valves.

Statutory recalibration tracking under GMP guidelines with laser-etched 316L stainless steel DataMatrix tags.
LEAD ARCHITECT ADVISORY • ON-SITE SCOPING

Architect Your Tooling, Asset & Calibration System

Consult directly with Jay Shah, Lead Architect at Arihant AI, on designing metallic QR identification, mobile scanner workflows, and automated calibration lockouts in Odoo.

On-site plant review in Ahmedabad, Sanand, Dahej, Hazira
Metallic QR plate material & laser-etching advisory
Odoo 17 / 18 / 19 Maintenance & MRP integration blueprint
ISO 9001 & IATF 16949 statutory audit mapping
DIRECT ARCHITECT CONNECTION
Connect on WhatsApp
+91 94095 58809 • [email protected]
Make Every Incoming Material Inspection Traceable
Capture samples, defects, measurements and photographs at the receiving dock—then connect the inspection result directly to Odoo, vendor decisions and quality scorecards.
H

Harsh

ERP & Solutions Lead

Helps businesses migrate to cloud ERP, streamline factory operations, and cut manual data entry.

Direct Advice & Support · Ahmedabad Team

Planning to Upgrade Your Factory, Warehouse, or Accounts to Cloud ERP?

Talk directly with our ERP team in Ahmedabad. We will review how your business works, show you live screens tailored to your work, and give you a clear plan without any sales pressure.

Smooth Tally to Cloud Setup
Chemical, Packaging & Factory Systems
Direct Solutions Architect Response

Talk to Our Ahmedabad Team

Choose how you want to connect:

100% Private & Confidential

Subscribe to Our Daily Digest

Get the latest insights on AI Agents, Odoo 19 implementation, CRM scaling, and workflow automations delivered straight to your inbox daily.
